The DS Series amps use Taramp's newest cutting edge technology. They are an evolution of the best-selling TS Series.

Technical Specs

• Number of Channels: 4
• Max Output Power:
• @ 12,6 VDC - 2 OHMs: 800W RMS (4 x 200W RMS)
• @ 12,6 VDC - 4 OHMS: 544W RMS (4 x 136W RMS)
• Signal Noise/Ratio: >88dB
• Frequency Response: 10Hz ~ 45KHz (-3dB)
• Input Impedance: 18K OHMS
• Minimum Supply Voltage: 9 VDC
• Maximum Supply Voltage: 16 VDC
• Idle Consumption: 1.4A
• Maximum Musical Consumption: @ 12,6 VDC: 43A
• Sinusoidal Signal Maximum Consumption: (1KHz) 12,6VDC: 86A
• Dimensions (WxHxD): 182 x 52 x 227mm
• Weight: 1.60Kg
