Additional Features:

• Remotely programmable via standard IEEE-488 interface
• Standard Resolution to 0.1 ppm
• Optional Resolution to 0.01 ppm
• Terminal Linearity 0.9 ppm
• Wide bandwidth — 10 Hz to 20 kHz
• Standard 0.35 V/Hz, 350 V Max
• Optional 2.5 V/Hz
• Overload protection
• Front panel display for easy set up and operation

The ESI PRT-73 Automated Precision Ratio Transformer meets or exceeds all of the requirements for a calibration standard in precision measurement applications. It is easily integrated into systems for either automated or manual calibration of ratio dividers, transformer standards, synchro/resolver standards, transformers, calibrators, and voltmeters.

The PRT-73 is fully programmable via a standard IEEE-488 interface. Storing calibration procedures in the system controller increases the repeatability of measurements.
