Features

• Family: LM386
• Minimum Single Supply Voltage : 4V
• Typical Single Supply Voltage: 5V/9V
• Maximum Single Supply Voltage: 12V
• Maximum Operating Temperature: 70°C
• Amplifier Type: Class-AB
• Output Type: 1-Channel Mono
• Maximum Load Resistance: 32 Ohm
• Supplier_Package : MDIP
• Maximum Quiescent Current: 8mA@6V
• Product Length: 9.27mm
• Total Harmonic Distortion Noise : 0.2%@8 Ohm @125mW
• Maximum Input Bias Current: 0.25uA(Typ)@6V
• Typical Output Power x Channels @ Load: 0.325Wx1@8Ohm
• Typical PSRR: 50dB
• Typical Quiescent Current: 4mA@6V
• Maximum Power Dissipation: 1250mW
• Rail to Rail: No
• Minimum Operating Temperature: 0°C
• Function: Speaker
• Mounting Through Hole
• Pin Count: 8
• Product Width: 6.35mm
• Product Height: 3.3mm
• Power Supply Type: Single
• Product Type: Audio Amplifier
• Typical Voltage Gain: 46dB
• Input Signal Type: Single
• Output Signal Type: Single
