Product Description
-
Supports HDCVI/AHD/TVI/CVBS/IP video inputs
-
Maximum 32 channels IP camera inputs, each channel up to 4MP
-
Maximum 128Mbps Incoming Bandwidth
-
H.264 /H.264 dual-stream video compression
-
Support 2 SATA HDD up to 8TB Each, 2 USB Ports
-
Supports 5MP camera input
-
HDMI/ VGA/ TV Simultaneous Video Output
-
Mobile Software: iCMOB, gCMOB
-
CMS Software: KVMS Pro
Product Specification
| Brand | CP Plus |
| Product Type | DVR |
| Product Model | CP-UVR-3201K2-V5 |
| Processor | Embedded processor |
| Operating System | Embedded LINUX |
| Ip Camera Input | 32Ch. each channel up to 4MP |
| Two-Way Talk | Reuse audio in/out, RCA |
| User Interface | GUI |
| Video Output | 1 HDMI, 1 VGA, 1 TV |
| Video Resolution | HDMI: 1920 x 1080, 1280 x 1024, 1280 x 720 VGA: 1920 x 1080, 1280 x 1024, 1280 x 720 |
| Video Recording | Main stream: All channel 5M-N(1fps–10fps); 4M-N/1080P(1 fps–15 fps); 720P/960H/D1/CIF(1 fps–25/30 fps); Sub stream: 960H(1 fps–15 fps); 1/CIF(1 fps–25/30 fps) |
| Resolution | 5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF, BCIF, QCIF |
| Video Compression | H.264 /H.264 |
| Video Display Split | 1/4/8/9/16/25/36 |
| Video Channel | 32 channel, BNC |
| Anomaly Alarm | No Disk, Disk Error, Low Space, Offline, IP Conflict, MAC Conflict |
| Alarm Linkage | Record, snapshot(panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email |
| General Alarm | Motion detection, Video Loss, tampering |
| Audio Input | 1 channel, RCA |
| Audio Output | 1 channel, RCA |
| Motion Detection | Supports |
| Video Loss | Supports |
| Smart Phone | iPhone, iPad, Android Phone |
| Face | Only for the 1st channel, only support analog camera |
| Hard Disk | 2 SATA port, up to 8TB Each |
| Bit Rate | 32Kbps ~ 6144Kbps Per Channel |
| Recording Mode | Manual, Schedule(General, Continuous), MD(Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Search Mode | Time/Date, Alarm, MD & Exact search(accurate to second) |
| Backup Mode | USB Device/Network |
| Playback | Instant playback, general playback, event playback, tag playback, smart playback(face and motion detection) |
| Maximum User Account | 128 users |
| Ethernet | 1 RJ-45 port(1000MB) |
| Interface Ports | 2 USB ports(1 USB 2.0, 1 USB 3.0), 1 RS485 Port |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, SNMP, UPnP
$
