Brand

CP Plus

Product Type

DVR

Product Model

CP-UVR-1601K1-V5

Processor

Embedded processor

Operating System

Embedded LINUX

Ip Camera Input

16 8: each channel up to 4MP

Two-Way Talk

Reuse audio in/out, RCA

User Interface

GUI

Video Output

1 HDMI, 1 VGA

Video Resolution

HDMI: 1920 x 1080, 1280 x 1024, 1280 x 720 VGA: 1920 x 1080, 1280 x 1024, 1280 x 720

Video Recording

Main stream: All channel 5M-N(1fps–10fps); 4M-N/1080p(1 fps–15 fps); 720P/960H/D1/CIF(1 fps–25/30 fps); Sub stream: 960H(1 fps–15 fps); 1/CIF(1 fps–25/30 fps)

Resolution

5MP, 4MP, 3MP, 1080P, 720P, 960H, D1, CIF, BCIF, QCIF

Video Compression

H.264 /H.264

Video Display Split

1/4/8/9/16

Video Channel

16 channels, BNC

Anomaly Alarm

No disk, disk error, low space, offline, IP conflict, MAC conflict

Alarm Linkage

Record, snapshot(panoramic), IPC external alarm output, access controller, voice prompt, buzzer, log, preset, email

General Alarm

Motion detection, Video Loss, tampering

Audio Input

1 channel, RCA

Audio Output

1 channel, RCA

Motion Detection

Supports

Video Loss

Supports

Smart Phone

iPhone, iPad, Android Phone

Face

Only for the 1st channel, only support analog camera

Hard Disk

1 SATA port, up to 8TB

Bit Rate

32Kbps ~ 6144Kbps Per Channel

Recording Mode

Manual, Schedule(General, Continuous), MD(Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop

Search Mode

Time/Date, Alarm, MD & Exact search(accurate to second)

Backup Mode

USB Device/Network

Playback

Instant playback, general playback, event playback, tag playback, smart playback(face and motion detection)

Maximum User Account

128 users

Ethernet

1 RJ-45 port(1000MB)

Interface Ports

2 USB ports(1 USB 2.0, 1 USB 3.0), 1 RS485 Port

Protocols

HTTP, HTTPS, TCP/IP, IPv4/IPv6, Wi-Fi, SNMP, UPnP, RTSP, SMTP, NTP, DHCP, DNS, PPPoE, DDNS, FTP, Alarm Server, IP Search, ONVIF(profile S), CGI, SDK

Power Supply

DC 12V/2A
