Product Details
＋
Strengths and benefits
- Dual extraction connector
- Simple routing height adjustment with a crank handle
- Arched routing hood for safe routing and optimised extraction
- Router module can be replaced by further CMS modules
Main applications
- All kinds of routing work: routing rebates, recesses, curves and shapes
- Routing shapes and curves at the ball bearing guide
- Jointing work at the stop
Items Included
- operation tool, module support, assembly lugs, router stop, press-down fixture, guard, ?? 8 mm clamping collet, chip deflector, basic unit with foldaway legs, ?? 12 mm clamping collet, copying ring ?? 30 mm, extraction hood, top, router OF 1400 EBQ-Plus, side stop with fine setting
Technical Details
- weight 4,5 kg
- Working height with legs 900 mm
- Power consumption 1400 W
- Connection ?? d/e 27/36 mm
- Table dimensions 585 x 400 mm
- Max. cutter diameter 60 mm
- Table height, legs folded away 316 mm
- Table height, legs unfolded 900 mm
- Idle engine speed 10000-22500 min???
- Dimensions module support 578 x 320 mm
- Weight module support 10,1 kg
- Basic unit weight 10,8 kg
- Weight (set) 25,4 kg
Commercial Information
- Net weight 0,000 kg
- Gross weight 0,000 kg
- Country of origin DE
- PU 1
- SU 1
Industry
Wood
Quantity In Pack
1
